CLA816M

The CLA816M is a mono amplified line source speaker with the following features:
– Medium (MF): 8 x 6’’ speakers
– High (HF): 1 x 1’’ compression driver
– MF: 1600W AES
– HF: 60W AES
– Nominal SPL (1): 130dB SPL
– Max SPL (2): 133dB SPL
– Freq. response (-6dB): 90Hz – 18kHz
– Directivity (-6dB): 100°H / 25°V
– Baltic birch wood
– Finished polyurethane paint
– H1600 x D320 x W200 mm – 33,5 Kg
– DSP control :
– Active filters ; Delay
– Inputs and outputs parametric EQs
(10 frequencies)
– Limiter / compressor
– Powered by Pascal® amplification
– 1 x XLR IN + 1 x XLR OUT
– RJ45 Input to program DSP
(1) theoretical value at long-term RMS power
(2) theoretical value at max power handling

Related applications

Specifications

See listed features of the CLA816 above
