The audio amplifier boasts of a Class D output circuitry with full bandwidth PWM modulator, resulting in ultra-low distortion for high-quality audio output. It has a Signal to Noise Ratio of over 119 dB, ensuring a neutral clear sound without any unwanted noise or distortion.
The amplifier also comes with several protection features, including short circuit protection, DC protection, under voltage protection, temperature protection, and overload protection, ensuring that the device remains safe and operational even under adverse conditions.
With up to 2000W of power, these amplifiers are designed to provide an exceptional sound experience for all types of applications, from live concerts to recording studios, clubs and conferences.
|AP2 SERIES 2-CHANNELS||AP2-140||AP2-280||AP2-500||AP2-800||AP2-3000|
|RL: 4 Ω||2 x 140 W||2 x 280 W||2 x 490W||2 x 810 W||2 x 3000 W|
|RL: 8 Ω||2 x 140 W||2 x 280 W||2 x 245W||2 x 410 W||2 x 1500 W|
|SE MODE CH1 + CH2||RL: 2 Ω||-||-||-||2 x 900 W||2 x 1500 W|
|RL: 4 Ω||140 W||280 W||1050 W||1400 W||-|
|RL: 8 Ω||140 W||280 W||900 W||1500 W||-|
|BTL MODE||70 V RMS||140 W||250 W||1000 W||1500 W||-|
|100 V RMS||120 W||240 W||1000 W||1500 W||-|
|AP4 SERIES 4-CHANNELS||AP4-140||AP4-280||AP4-500||AP4-800|
|RL: 4 Ω||4 x 140 W||4 x 280 W||4 x 490W||4 x 810 W|
|RL: 8 Ω||4 x 140 W||4 x 280 W||4 x 245W||4 x 410 W|
|SE MODE CH1 + CH2||RL: 2 Ω||-||-||-||4 x 900 W|
|RL: 4 Ω||2 x 140 W||2 x 280 W||2 x 1050 W||2 x 1400 W|
|RL: 8 Ω||2 x 140 W||2 x 280 W||2 x 900 W||2 x 1500 W|
|BTL MODE||70 V RMS||2 x 140 W||2 x 250 W||2 x 1000 W||2 x 1500 W|
|100 V RMS||2 x 120 W||2 x 240 W||2 x 1000 W||2 x 1500 W|
