The BZ5 is an 80W AES power full range speaker at 8 ohms. It comprises 5′ low-frequency and 3′ medium-frequency vented enclosed loudspeakers, as well as a 0.25′ tweeter.


  Best advantages

Applicable to small, medium-sized and large venues

Directivity (-6dB): 100° H x 60° V

Although mostly sold in black, the BZ5 can be painted white or a wide range of other RAL colours upon request


AES Power: 80 W / 8 Ω
Bandwidth (-6dB): 90 Hz to 20 KHz
Sensitivity: 88 dB / 1W @1m
SPL MAX level: 107 dB
Directivity (-6dB): 100° H x 60° V
LF: 1 x 5’’ vented enclosure
MF: 1 x 3’’ vented enclosure
HF: 1 x 0.25’’ tweeter
Connections: 2 Spk NL4 or Phoenix 4 pts
Rigging: 1 x M10 (for bracket)
2 x M6 (for wall mounting ball)
1 x M6 (for safety chain)
12 mm baltic birch wood
Finished polyurethane painting
Dim. H370 x D247 x W144 mm / Wht 4.5 kg

Product compatibility





Available options:
BZ5-PB Phoenix Black
BZ5-SB Speakon Black
BZ5-PW Phoenix White
BZ5-SW Speakon White
BZ5/*C Colour (RAL) upon request
For Phoenix versions all connectors are included.
