CBA12

CBA12 bass cabinet



Key features

Available as a passive version as well as mono and stereo amplified versions

Well-suited to small and medium-sized concerts

Bandwidth: 50 Hz to 220 Hz



Amplified Versions

– Power: 2 x Powercon In/Out
– Pascal Audio amplifier
– «All DSP» with ethernet



Related applications

Large Congregations

residential

Residential

stadium-sport-venues

Stadium & Sport Venues

restaurants-cafes

Restaurants & Cafes

hotels-resorts

Hotels & Resorts

Nightclubs & Lounges

Nightclubs & Lounges

auditoriums-concert-halls

Auditorium & Concert Halls

Specifications

LF: 1 x 12” band pass 6th order enclosure
Bandwidth (-6dB): 50 Hz to 220 Hz
Directivity: 180° cardioid
Rigging: 1 socket for tube M20
- 18 mm baltic birch wood
- Dim. H447 x D460 x W450mm / Wht: 27 Kg


Available options
CBA12P - Passive
700 W AES / 8 Ω / Speakon 4 pts.
CBA12M - Mono amplified
2-way 1000 W + 250 W + DSP
CBA12S - Stereo amplified
3-way 1000 W + 2 x 250 W + DSP

Product compatibility

CLA85

CLA88

Q5

Downloads

Datasheet

High res.
